Aerogel Granules/Powder are inorganic materials featuring a three - dimensional nanoporous network structure, with porosity reaching 80-99%, pore sizes concentrated between 10-50nm, and thermal conductivity as low as 0.017W/(m·K). They demonstrate broad applications in thermal management, acoustics, mechanics, optics, electronics, and pharmaceuticals. IBIH offers hydrophobic aerogel granules, translucent aerogel granules, and aerogel powder.
Aerogel Granules/Powder
Aerogel Granules/Powder are inorganic materials featuring a three-dimensional nanoporous network structure, with porosity reaching 80-99%, pore sizes concentrated between 10-50nm, and thermal conductivity as low as 0.017W/(m·K).
- OVERVIEW
- PRODUCT PARAMETERS
- APPLICATION FIELD
Product Features
KSL6PC-SH
| Property | KSL6 PC01-SH | KSL6 PC04-SH | |
| Composition | Silica Aerogel | Silica Aerogel | |
| Purity | 99.0%MIN | 99.0%MIN | |
| Particle Size Range | 0-1mm | 0-4mm | |
| Bulk Density | 60±10kg/m³ | 55±10kg/m³ | |
| Thermal Conductivity(25°C) | ≤0.023W/(m·k) | ≤0.023W/(m·k) | |
| Surface Chemistry | Hydrophobic | Hydrophobic | |
KSL6PC-T
| Property | KSL6 PC-TS | KSL6 PC-TL | |
| Composition | Silica Aerogel | Silica Aerogel | |
| Purity | 99.0%MIN | 99.0%MIN | |
| Particle Size Range | 0-1mm | 1-4mm | |
| Bulk Density | 45±10kg/m³ | 45±10kg/m³ | |
| Thermal Conductivity(25°C) | ≤0.023W/(m·k) | ≤0.023W/(m·k) | |
| Surface Chemistry | Hydrophobic | Hydrophobic | |
| Light Transmission | 80%-95% | 85%-95% | |
KSL6PD—SH
| Property | KSL6 PD-SH | |
| Composition | Silica Aerogel | |
| Purity | 99.0%MIN | |
| Particle Size Range | ≤50um | |
| Tap Density | 55±10kg/m³ | |
| Thermal Conductivity(25°C) | ≤0.021W/(m·k) | |
| Surface Chemistry | Hydrophobic | |
Application Field
KSL6 PC-SH available for
Compound with different base material to make aerogel composite thermal insulation felt.
Primary material to make aerogel thermal insulation plaster.
Functional additives and filler in high performance insulation systems.
KSL6 PC-T available for
Insulating Glass Systems: Enhances insulation performance in glass units and curtain wallswhile maintaining excellent light transmission.
Daylighting Solutions: Used in skylights and translucent panels,allowing natural light while ensuring energy efficiency.
Specialized Uses: Applied in greenhouses，sunrooms, noise-reducing glazing, combining insulation, light transmission.
KSL6 PD-SH available for
Compound with different base material to make aerogel composite thermal insulation felt.
Primary material to make aerogel thermal insulation coating.
Functional additives and filler in high performance insulation systems.
