Aerogel High-temperature Insulation Blankets
- OVERVIEW
- PRODUCT PARAMETERS
- APPLICATION FIELD
-
Grade A incombustibility
Meets the grade A incombustibility rating of the GB8624-2012 Classification for Burning Behavior of Building Materials and Products. -
Low thermal conductivity
The thermal conductivity is 0.017~0.021W/(m·K) at 25℃; the thermal conductivity is 0.032~0.042W/(m·K) at 300℃, and the thermal insulation thickness is only 1/5~1/3 of traditional fiber materials. -
Long service life
Stable nanoporous structure, high compression resilience, inorganic aging resistance, and superior hydrophobicity, with an effective service life equivalent to that of pipeline equipment. -
Environment friendly
The product does not contain any asbestos, benzene, formaldehyde, or other harmful substances, and can be reused after equipment maintenance and disassembly. It is environmentally friendly and free of the need to deal with industrial waste disposal. -
High hydrophobicity and permeability
The hydrophobicity rate reaches 98%. The product is also non-hygroscopic, and can effectively prevent the accumulation of internal moisture, eliminating corrosion under insulation (CUI), and extending the service life of pipes and equipment.
Product Features
| Model | KSL845 | KSL865 | |
| Thickness | 3mm/5mm/6mm/10mm | 3mm/5mm/6mm/10mm | |
| Width | 1500(-3,+15) mm | 1500(-3,+15) mm | |
| Unit Weight | 200±20kg/m³ ( customizable upon request) | 180±20kg/m³ (customizable upon request) | |
| Colour | White | White or light brown | |
| Thermal Conductivity | Average Temperature 25℃ | ≤0.021W/(m・K) | ≤0.021W/(m・K) |
| Average Temperature 300℃ | ≤0.036W/(m・K) | ≤0.036W/(m・K) | |
| Average Temperature 500℃ | - | ≤0.072W/(m・K) | |
| Maximum Service Ttemperature | ≤450℃ | ≤650℃ | |
| Long-term Use Temperature | ≤400℃ | ≤550℃ | |
| Hydrophilicity and Hydrophobicity | The water repellency rate is not less than 98% for waterproofing and moisture-proofing requirements. | ||
Application Field
KSL8 is mainly applicable in providing thermal insulation and energy conversation for medium and high temperature pipelines and equipment, including but not limited to the following applications: steam and heat transfer oil pipelines and equipment in petroleum, chemical, pharmaceutical, and other industries, steam turbines, high and medium pressure pipelines, heat transmission pipelines in the thermal power industry, steam pipelines and smoke exhaust pipes on large ships, and the thermal insulation fireproofing layers in bullet trains, automobiles, and other vehicles.
